4-point truss system
ALUTRUSS QUADLOCK 6082-3000 4-Way Cross Beam
- Strong EN-AW 6082 alloy for high loads
- High-quality aluminum-tubes with 50 mm in diameter
- Low weight
- Distance center - center: 240 mm
- Easy installation
- Trusspipe: 50 mm
- TÜV Süd certified
- For application areas such as: Theater; Trade fair and shop fitting; Clubs/dancing school
- For further information about this product, please refer to the Data Sheet under "Downloads"
Package contents
- 1 x connection Set
ALUTRUSS QUADLOCK 6082L-30 3-Way Corner 90°
4-point truss system
- Strong EN-AW 6082 alloy for high loads
- High-quality aluminum-tubes with 50 mm in diameter
- Low weight
- Distance center - center: 240 mm
- Easy installation
- Trusspipe: 50 mm
- Made in Europe
- For application areas such as: Theater; Trade fair and shop fitting; Clubs/dancing school
Package contents
- 2 x connection Set
ALUTRUSS QUICK-LOCK Spare Pivot with Pin
QUICK-LOCK set
- Accessories for the robust truss system with Quick-Lock
- For use with TRI/QUAD system
- Trusspipe: 50 mm
- Made in Europe
Package contents
- 2 x splint, 2 x bolt
ALUTRUSS QUADLOCK End Plate QQGP-Male M-10
Baseplate for mobile use (connectors 6082 included)
- Easy installation
- The article is delivered pre-assembled
- Trusspipe: 50 mm
- Made in Europe
- Application possibility: Standing
half cone
- M10 thread
Package contents
- 1 x plate, 4 x half cone
Paraméterek
| Weight | 173,83 kg |
| ALUTRUSS QUADLOCK 6082-3000 4-Way Cross Beam | |
| Setup | Easy installation |
| Trusspipe | 50 mm x 2 mm |
| Welding technique | TIG-welding |
| Welding material | AlMg 5 |
| Alloy | AIMgSi1 T6 |
| Color | Alu colored |
| Strut diameter x thickness | 16 x 2mm |
| Dimensions | Length:3 m |
| Width | 29 cm |
| Height | 29 cm |
| Weight | 14,2 kg |
| ALUTRUSS QUADLOCK 6082L-30 3-Way Corner 90° | |
| Setup | Easy installation |
| Trusspipe | 50 mm x 2 mm |
| Color | Alu colored |
| Strut diameter x thickness | 16 x 2mm |
| Dimensions | Length:50 cm |
| Width | 50 cm |
| Height | 50 cm |
| Weight | 7,95 kg |
| ALUTRUSS QUICK-LOCK Spare Pivot with Pin | |
| Trusspipe | 50 mm |
| Color | Alu colored |
| Weight | 90 g |
| ALUTRUSS QUADLOCK End Plate QQGP-Male M-10 | |
| Setup | Easy installation |
| Trusspipe | 50 mm |
| Material | Aluminum |
| Color | Alu colored |
| Dimensions | Length:30,7 cm |
| Width | 30,7 cm |
| Height | 5 cm |
| Weight | 1,55 kg |
| Half cone | |
| Thread | M10 thread |
