Leírás
Fanless PC spot (DMX), 57 W LED in warm white, color rendering index (CRI) >90
- 1 powerful LED 57 W COB (chip-on-board) warm white (WW)
- Strobe effect
- The device is cooled by passive convection cooling
- Control via stand-alone; DMX
- Flicker-free
- With a beam angle of 11° - 48°
- Very high color rendering index (CRI)
- With Mounting bracket
- LCD display
- Dimmer electronic; dimmer curves with adjustable response; Dimmer speed (step response) adjustable
- Preprogrammed in LED PC-Control 512; Light´J; Light Captain
- Rubber feet
- Silent operation
- For application areas such as: Trade fair and shop fitting; Installation; Stage; theater
- Application possibility: Suspended; on stand
Package contents
- 1 x spotlight, 1 x barndoor, 1 x filter frame, 1 x user manual
Manuals
ManualsParaméterek
| Power supply | 100-240 V AC, 50/60 Hz |
| Power consumption | 40 W |
| IP classification | IP20 |
| Protection class | Protection class I |
| Power connection | Fixed power supply cord with safety plug |
| Fuse | 5 x 20 mm, T 1 A Fuse replaceable |
| LED | 1 x 57 W COB (chip-on-board) warm white (WW) |
| Color temperature | 3100K |
| DMX channels | 1; 2 |
| DMX input | 3-pin XLR (M) mounting version |
| DMX output | 3-pin XLR (F) mounting version |
| Cooling | Passive convection cooling |
| Control | Stand-alone; DMX |
| Preprogrammed in | LED PC-Control 512; Light´J; Light Captain |
| Projection | Flicker-free |
| Beam angle | 11° - 48° |
| Beam angle (1/2 peak) | 11 - 37° |
| Beam angle (1/10 peak) | 17 - 48° |
| Color rendering index (CRI) | 91 Ra |
| Illuminance in Lux (lx) | Narrow 3m:1656 lx, 6m:424 lx |
| Wide 3m | 348 lx, 6m:103 lx |
| Housing color | Black |
| Attachment system | Mounting bracket |
| Display type | LCD display |
| Transport aid | Rubber feet |
| Material | Aluminum casting |
| Slot for spot length | 13,1 cm x 13,1 cm |
| Dimensions | Length:27,5 cm |
| Width | 20,5 cm |
| Depth | 25 cm |
| Weight | 3,85 kg |
| Noise classification | Class 0 (no noise at all) |
| Mounting bracket | |
| Diameter mounting holes | 1 x Ø10mm; 2 x Ø6mm |
| Material | Metal, 3 mm |
| Power cord | |
| Cable construction | 3 x 0,75 mm² H05VV-F |
| Cable length | Approx. 1 m |
| Barndoor | |
| Material | Aluminum, 1,5 mm; metal |
| Ring diameter | Outside:12,9 mm |
| Inside | 10,9 mm |
| Filter frame | |
| Diameter mounting holes | 1 x Ø4mm |
| Shape | Octagonal |
| Material | Aluminum, 0,8 mm |
| Dimensions | Width:13 cm |
| Height | 13 cm |
| Diameter | Ø 10,5 cm |
| Legal specifications | |
| Special product | Not designed for household room illumination |
| Intended use | Show effect lighting |
