Leírás
Pinspot for PAR-36 6 V/30 W lamp
- At a distance of 4 m there is projected a light circle with a diameter of 30 cm
- Separately capsuled transformator chamber
- Color caps or color foils can be attached in front of the lens
- For illuminating e.g. mirror balls, entrance or counter areas or as basic illumination
- Interesting price levels for purchase of larger quantities
- Low power consumption
- Control via plug and play
- With Mounting bracket
- Various versions available
Package contents
- 1 x spotlight, 1 x lamp clamping ring, 1 x user manual
Manuals
ManualsParaméterek
Power supply | 230 V AC, 50 Hz |
Power consumption | Max. 30 W |
IP classification | IP20 |
Protection class | Protection class I |
Suitable lamp | Max. 6,4 V/30 W PAR-36 G-53 STC |
Power connection | Fixed Supply cord with open wires |
Cable construction | 3 x 0,75 mm² H05VV-F |
Cable length | Approx. 0,9 m |
Base | Wires |
Control | Plug and play |
Housing color | Black matte |
Attachment system | Mounting bracket |
Material | Metal |
Dimensions | Length:16 cm |
Width | 15,5 cm |
Height | 17 cm |
Weight | 1,00 kg |
Lamp clamping ring | |
Material | Metal |
Color | Silver |
Mounting bracket | |
Diameter mounting holes | 3 x Ø10mm; 1 x Ø8mm |
Material | Metal, 2 mm |
Legal specifications | |
Special product | Not designed for household room illumination |
Intended use | Show effect lighting |
