Leírás
Class H PA amplifier with limiter, 2 x 1350 W RMS (4 ohms), 2 x 1080 W RMS (8 ohms)
- 3 operating modes can be selected (stereo, parallel or bridged)
- Input sensitivity adjustable
- 2 level controls
- Each channel with LED for activated protective circuit (protect) and output meter with clip LED
- Signal inputs via XLR or RCA connectors
- Speaker outputs via lockable speaker jacks and pairs of screw terminals
- Class H circuitry
- The device is cooled by cooling fan
- (19") 48.3 cm rack installation 2 U
- For application areas such as: Clubs/dancing school; Installation; mobile use; mobile djs / entertainer; restaurants, bars and hotels; Rental; sports centres/gyms
Package contents
- 1 x amplifier, 1 x user manual, 1 x power cord, 4 x foot, 4 x screw
Manuals
ManualsParaméterek
Power supply | 230 V AC, 50 Hz |
Power consumption | 700 W 1/8 power |
Output power | 2 x 1350 W RMS (4 ohms); 2 x 1080 W RMS (8 ohms); 2700 W RMS bridged (8 ohms) |
Power connection | Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided) |
Frequency range | 20 - 20000 Hz |
S/N ratio | >100 dB |
THD | <0,5 % at 1 kHz |
Cooling | Cooling fan |
Impedance | Input:20 kOhm , bal. |
Input | 10 kOhm , unbal. |
Circuitry | Class H |
Slew rate | >10 V/µs |
Damping factor | >200 |
Control elements | Power switch, level control per channel, mode switch (stereo/parallel/bridged), Input sensitivity switch |
Controls | Short-circuit; overheat; DC voltage; power on/off transients; softstart; power on/off transient |
Status LED | Power, level meter, clip, bridged, protect |
Connections | Input:line via 2 x 3-pin XLR |
Input | line via 1 x stereo RCA |
Output | speaker via 2 x speaker built-in socket (F) |
Output | speaker via screw terminal |
Input sensitivity | 0,775 V; 1,4 V , switchable |
Housing design | (19") 48.3 cm rack installation 2 U |
Dimensions | Width:48,3 cm |
Depth | 41,5 cm |
Height | 8,9 cm |
Weight | 15,70 kg |
