Leírás
2-channel multifrequency wireless receiver with high-quality diversity reception
The UR-222D is an affordable and reliable UHF system for everyday use. The device works with 90 channel presets in 10 groups. 9 channels can be operated in parallel. True diversity receiver technology, pilot tone and adjustable noise squelch guarantee reliable transmission. Setup is quick and easy using auto-scan and infrared sync.
- 10 groups with 90 fixed frequencies within 11 MHz switching bandwidth
- Pilot frequency squelch technology delete wireless RF interference
- Automatic frequency scan (AFS) finds interference-free channels
- Easy and error-free synchronization between receiver and transmitter via infrared signal
- 2 detachable BNC antennas allow for use with the R-14D antenna divider
- Rugged metal housing
- Multicolor LCD display
- UHF 863 - 865 MHz License-free and approved in Europe
- UHF 823 - 832 MHz License-free and approved in large parts of Europe
- Operating range up to 80m with line-of-sight
- Desktop console housing
- (19") 48.3 cm rack installation possible 1 U
- Up to 9 transmitters can be operated in parallel without interference
- Charge status indicator
Package contents
- 1 x receiver, 1 x external mains adapter, 2 x antenna, 2 x mounting bracket, 6 x screw, 2 x jack cable, 1 x user manual, 1 x declaration of conformity
Manuals
ManualsParaméterek
Type | Receiver |
Power supply | 100-240 V AC, 50/60 Hz |
12V DC 1000 mA | |
Power consumption | 5 W |
Power connection | Mains input via coaxial power connector (M) mounting version power supply cord with AC adapter (provided) |
Number of channels | 2 |
Frequency range | 45 - 18000 Hz |
S/N ratio | >105 dB |
Range | Range up to 80m with line-of-sight |
Frequency band | UHF 863 - 865 MHz; UHF 823 - 832 MHz |
Diversity | Antenna diversity |
Switching bandwidth | 11 MHz |
Frequency stability | ± 0,0005 % |
Parallel mode | Max. 9 transmitter |
Modulation | FM |
Frequency selection | 90 switchable frequencies |
In 10 groups with up to 10 preset frequencies each | |
Display type | Multicolor LCD display |
Display | Channel , frequency , goup , RF signal level; AF audio level , antenna A/B , charge status indicator |
Control elements | Navigation keys, menu, groundlift selector |
Connections | Output:line via 2 x 3-pin XLR |
Output | line via 2 x 6.3 mm plug (unbal.) |
Antenna via 2 x BNC (F) 8 V | |
Material | Metal |
Color | Black |
Housing design | Desktop console housing |
(19") 48.3 cm rack installation possible 1 U | |
Dimensions | Width:41 cm |
Depth | 26 cm |
Height | 4,6 cm |
Weight | 2,32 kg |
