Leírás
Rack case
Flightcase for 483 mm devices (19")Transport your 19" control and effect units easily and safely with the ROADINGER CO DD effect rack. The two removable lids (double door version) and the built-in rack rails make the handling with the flightcase comfortable.The high-quality workmanship with multi-layer glued wood with a wall thickness of 7 mm ensures durability. The case gets additional stability by the aluminium profile frame with rounded corners and the three-legged, medium-sized steel ball corners.The flight case is equipped with eight snap locks with eyelets for locking as well as two large chrome-plated case folding handles. The four large, steel-reinforced rubber feet provide the necessary stability.The maximum load is 25 kg.
- Built-in rack rails
- High-quality workmanship with plywood multi-layer glued 7 mm, black, laminated
- Aluminum profile frames 22mm with rounded edges
- 2 hinged, chromium plated case handles
- 8 high-quality spring locks with shut-off function
- Rubber feet
- Available in different height units (1 U = 44 mm)
- With profile rails suitable for 19" units
- 6 U
- For further information about this product, please refer to the Data Sheet under "Downloads"
Paraméterek
| Maximum load | 25 kg |
| Aluminum profile frames | 22 mm |
| Case handle | 2 pc/pcs |
| Lock | Spring lock:8 pc/pcs with shut-off function |
| Transport aid | Rubber feet |
| Material | Plywood multi-layer glued, 7 mm |
| Color | Black, laminated |
| Front panel width | 19" |
| Mounting height | Approx. 26.5 cm (6 U) |
| Mounting depth | 250 mm |
| Housing design | 6 U |
| Dimensions | Width:52,5 cm |
| Depth | 40,5 cm |
| Height | 31 cm |
| Weight | 7,50 kg |
